• MOZECTM NC PTCA Balloon Dilatation Catheter is indicated for balloon dilatation of the stenotic portion of a coronary artery or a bypass graft stenosis for the purpose of improving myocardial perfusion and also for post-delivery expansion of balloon expandable stents.
  • US-FDA approved and also available in China, Japan, Canada, Australia, Korea, Latin America, Asia, Middle-East & Africa.
  • Low 0.019” distal tip entry profile ensures navigation post stent deployment.
  • Small abrupt balloon shoulders help avoid injury to healthy vessel adjacent to the lesion.
  • MeriStemTM hypo-tube shaft for enhanced support and pushability with MeriGlideTM hydrophilic coating on distal shaft for smooth trackability.
  • Swaged low profile RO marker band for accurate visibility.
  • 5 Fr Guide catheter compatible and 6F compatibility for kissing balloon.
MOZEC PTCA Balloon Catheter



Product Specifications

Catheter Design Rapid Exchange
Tip Entry Profile 0.019”
Crossing Profile 0.70-1.40 mm
Balloon material composition Nylon (Non-Compliant)
Balloon Compliance Non-Compliant
Hydrophilic Coating MeriGlideTM - from base of distal tip to Rx-port
Nominal 12atm
RBP 20atm


Size Chart

DIA/Length 8 mm 12 mm 13 mm 15 mm 18 mm 23 mm 28 mm 30 mm 35 mm 38 mm
2.00 mm MNC20008 MNC20012 MNC20013 MNC20015 MNC20018 MNC23023 MNC20028 MNC20030 MNC20035 MNC20038
2.25 mm MNC22508 MNC22512 MNC22513 MNC22515 MNC22518 MNC22523 MNC22828 MNC22530 MNC22535 MNC22538
2.50 mm MNC25008 MNC25012 MNC25013 MNC25015 MNC25018 MNC25023 MNC28028 MNC25030 MNC25035 MNC25038
2.75 mm MNC27508 MNC27512 MNC27513 MNC27515 MNC27518 MNC27523 MNC27528 MNC27530 MNC27535 MNC27538
3.00 mm MNC30008 MNC30012 MNC30013 MNC30015 MNC30018 MNC30023 MNC30028 MNC30030 MNC30035 MNC30038
3.25 mm MNC32508 MNC32512 MNC32513 MNC32515 MNC32518 MNC32523 MNC32828 MNC32530 MNC32535 MNC32538
3.50 mm MNC35008 MNC35012 MNC35013 MNC35015 MNC35018 MNC35023 MNC35028 MNC35030 MNC35035 MNC35038
4.00 mm MNC40008 MNC40012 MNC40013 MNC40015 MNC40018 MNC40023 MNC40028 MNC40030 MNC40035 MNC40038
4.50 mm MNC45008 MNC45012 MNC45013 MNC45015 MNC45018 MNC45023 MNC45028 MNC45030 MNC45035 MNC45038
5.00 mm MNC50008 MNC50012 MNC50013 MNC50015 MNC50018 MNC50023 MNC50028 MNC50030 - -


Contact your country local Meril sales representative for availibility of sizes highlighted in blue

Clinical Data

Product IFU

Note: IFU will be displayed after MDR Certification
